Rotary Volumetric Filling & Sealing Machine

Liquid/ Dairy section

Rotary Volumetric Filling & Sealing Machine

Salient Features

  • Rigid vibration free construction for trouble free performance.
  • S.S. Elegantly matt-finished body.
  • Elegant and easy control panel for total control on operation.
  • Minimum change over time from one size to another container or fill size.
  • Automatic washing of conveyor belt (Optional).

TECHNICAL SPECIFICATION

Technical Specification

Two Head
Four Head
Six Head
Eight Head
Output/Hour
2400/Hour
4800/Hour
7200/Hour
9600/Hour
Capacity 10ml to 500ml –With the help of change parts
Accuracy ± 1 % Filling accuracy on single doze
Electrical Rating
Main Machine Motor 1.00 H.P. (for Two/Four/Six Head Machine)
Conveyor Motor 1.50 H.P. (for Head Head Machine)
Power required 440 Volts, 50 Hz
Dimensions (in mm) 1500 L x 800 W x 1500 H (of Two & Four Head Machine)
Conveyor Height 780mm to 860mm adjustable
Input specifications Dia. 30mm x 80 mm
